Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing

Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing

Product Details:

Place of Origin: Anhui, China
Brand Name: WNK
Model Number: WNK 8010

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: $35.00 - $50.00/Pieces
Packaging Details: cartons
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union, MoneyGram, Paypal
Supply Ability: 3000 Piece/Pieces per Month
Get Best Price Contact Now

Detail Information

Warranty: 1 Year Customized Support: OEM, ODM
Output Signal: 4-20mA, 0-5V, 1-5V, 0.5-4.5V, 0-10V Accuracy: 0.2%FS, 0.5%FS
Pressure Type: Gauge Power Supply: 12~36VDC
Housing Material: 304SS, 316L Measuring Medium: Rainwater, Drinking Water,Wastewater, Sewage, Oil
Stability: 0.2%FS/year Protection Class: IP68
Overload: 1.5 Times Working Temperature: -40~85 ℃
Port: Shanghai
High Light:

304SS Housing Submersible Water Level Sensor

,

Tank Rivers Measuring Submersible Level Transmitter

,

IP68 Submersible Water Level Sensor

Product Description

4-20ma 0.5-4.5V Water Level Sensor /Submersible Level Transmitter For Tank Rivers Measuring

WNK 4-20ma 0.5-4.5V Water Level Sensor


Specification



Our WNK8010 liquid leve probe with high performance diffused silicon piezoresistive pressure sensor as the measuring element, With the reliable amplified circuit and precision temperature compensation, to transfer the gauge or bsolute pressure of measurement medium to standard voltage or current signal. This product comes with compact profile, easy to install, it can measure the level height directly when through into the liquor.

Applications

Water tank level measurement and control.

Fuel tank level measurement and monitor (diesel, gasoline, kerosene and so on).

Liquid level measuring in tank, rivers, lake, sea, well, tube, underground water and so on.

Special occasion such as high temperature liquid (up to 100 degree C), strongly corrosion liquid level measurement (request by customized.)



Features

Adopting diffusion silicon oil-filled sensor

Max measure range up to 200 meters or more

High Stability, provide 0.1, 0.2, 0.5 accuracy for option

Factory direct price



 Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 0Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 2Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 4Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 6Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 8Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 10







Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 12

Company Information


 Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 14Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 16Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 18Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 20

Certifications

Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 22

Packaging & Shipping

Submersible Water Level Sensor For Tank Rivers Measuring 304SS Housing 24

FAQ

Q: Are you manufacturer or trading company?

A: We are 13-year professional manufacturer of Pressure/ Level/ Temperature transmitters with 4~20mA, Hart, Profibus & FF protocols, pressure sensors with SPI, I2C, 4~20mA, 0.5~4.5V and etc, and electronic switches. We provide high quality products with high competitive factory price.



Q: What’s your quality control system?

A: As an ISO9001:2015 certificated manufacturer, we have strict quality control system, and each product is done fatigue testing, calibration, temperature compensation before shipment. High quality is guaranteed.



Q: Is there MOQ with your product?

A: We have no MOQ limits, 1pc for testing purpose is acceptable.



Q: Can we print our logo on the products? Do you provide customized products?

A: Yes, we can print your logo on our products; OEM, ODM&customization are welcomed.



Q: What is the warranty of your products? And after-sales service?

A: Our warranty time is 12 months after shipment, and our after-sales dpt will respond with your questions in 24hrs, remote instruction by PC network is always available.



Q: What is lead time of your product?

A: We are factory, our lead time is always within 7 working days for products without customization, but lead time for flange products is a little longer.
