Hydraulic Piezo Micro Pressure Transducer SPI For Water Treatment System
Product Details:
Place of Origin: | Anhui, China |
Brand Name: | WNK |
Model Number: | WNK80MA |
Payment & Shipping Terms:
Minimum Order Quantity: | 1pcs |
---|---|
Price: | $12.00 - $19.00/Pieces |
Packaging Details: | Each piece into individual carton with foam protection<br>Or as per client's request |
Delivery Time: | 5-8 work days |
Payment Terms: | T/T, Western Union, MoneyGram, Paypal |
Supply Ability: | 3000 Piece/Pieces per Month hydraulic pressure sensor |
Detail Information |
|||
Accuracy: | 0.2% 0.5% 1.0% FS | Output Signal: | 4- 20mA, 0-5V, 1-5V, 0.5-4.5V, 0-10V |
---|---|---|---|
Operating Temperature: | -40~85 ℃ | Pressure Range: | -100Kpa ~ 60MPa |
Housing Material: | 304SS, 316L, 316SS | Measured Media: | Liquid, Gas, Steam, Oil, Air |
Power Supply: | 5V DC, 12-32V DC | IP Rating: | IP65, IP67 |
Type: | Pressure Sensor | Product Name: | 4-20mA Industrial Liquid Water Piezo Hydraulic Pressure Sensor |
Port: | Shanghai/Ningbo | ||
High Light: | Hydraulic Piezo Pressure Sensor,Water Treatment Micro Pressure Transducer,SPI water pressure sensors |
Product Description
Specifications
4-20mA Industrial Liquid Water Piezo Hydraulic Pressure Sensor
Input | |
Pressure Type | Gauge Pressure , Absolute Pressure, Sealing Pressure |
Pressure Range | -100Kpa - 60Mpa |
Accuracy | 0.2%, 0.5% |
Power Supply | 5VDC, 12-32VDC |
Measuring Media | Gas, Steam, Liquid, Oil |
Output | |
Analog | 4-20mA, 0.5-4.5V / 1-5V / 0-5V |
Digital | I2C, SPI |
Operation Condition and Temperature | |
Compensation Temperature | -20...75℃ |
Storage Temperature | -45 ... 85℃ |
Ambient Temperature | -45 ... 85℃ |
Medium Temperature | -40 ... 125℃ |
Material and Protection | |
Ingress Protection | IP65, IP67 |
Housing Material | 304SS, 316L |
>>> Applications |
- Automobile, Compressor and Refrigeration Industry |
- Engineering machinery |
- Pressure control and monitor |
- Water treatment system |
- Hydraulic and Pneumatics |
- HAVC and BAS Control |
- Pump, fitness equipment, household appliances |
- Factory Automation |
- Fluid Control and Instrumentation Systems |
