Product Details:

Place of Origin: Anhui, China
Brand Name: WNK
Model Number: WNK8010-TT

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: $35.00 - $50.00/Sets
Packaging Details: Each set in one individual carton packing with protection
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union, MoneyGram, Paypal
Supply Ability: 200 Set/Sets per Day Water level transmitter
Get Best Price Contact Now

Detail Information

Grade: Industrial Warranty: 1 YEAR
Customized Support: OEM, ODM Protection Class: Liquid, Water
Housing Material: Stainless Steel Accuracy: ±0.25% FS/year, ±0.5% FS/year
Output: 4-20mA, 1-5V, 0.5-4.5, 0-5V, 0-10V, IIC,HART,RS485 Power Supply: 24V/12V/5V/3.3V
Ambient/Process/Compensation Temperature: -20~80℃ Ingress Protection: IP68
Keywords: Water Level Sensor/liquid Level Sensor MOQ: 1 Sets
Product Name: 4-20mA 0.5-4.5V Analog Level Sensor Transmitter For Water Liquid Port: Shanghai
High Light:

4.5V Analog Water Level Sensor

,

4 20mA Analog Water Level Sensor

,

Intergral Small analog level transmitter

Product Description

 4-20mA 0.5-4.5V Analog Level Sensor Transmitter For Water Liquid
Packaging & Shipping

WNK8010

Adopting diffusion silicon oil-filled sensor

High Stability

Intergral small size

For tank, pool, underwater etc open vessel measurement

Product Name
 4-20mA 0.5-4.5V Analog Level Sensor Transmitter For Water Liquid
Pressure measurment
Liquid,Water
Accuracy
±0.25% FS/year, ±0.5% FS/year
Output
4-20mA, 1-5V, 0.5-4.5, 0-5V, 0-10V, IIC,HART,RS485
Power supply
24V/12V/5V/3.3V
Ambient/Process/Compensation temperature
-20~80℃
Housing material
Stainless steel
Ingress Protection
IP68

4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 0





4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 2

4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 4

 4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 6
4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 8
4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 10
4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 12

-  Our WNK8010 liquid leve sensor with high performance diffused silicon piezoresistive pressure sensor as the measuring element,

-   With the reliable amplified circuit and precision temperature compensation, to transfer the gauge or absolute pressure of measurement medium to standard voltage or current signal.

 This product comes with compact profile, easy to install, it can measure the level height directly when through into the liquor.



Applications

•   Water tank level measurement and control.

•   Fuel tank level measurement and monitor (diesel, gasoline, kerosene and so on).

•   Liquid level measuring in tank, rivers, lake, sea, well, tube, underground water and so on.

•  Special occasion such as high temperature liquid (up to 100 degree C), strongly corrosion liquid level measurement (request by customized.)



 Features

•   Adopting diffusion silicon oil-filled sensor

•   Max measure range up to 200 meters or more

•   High Stability, provide 0.1, 0.2, 0.5 accuracy for option

•   Factory direct price





 4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 14



Specifications

 4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 16


   Low cost Water Level Sensor for Deep Well, Open Tank, Pool

Ordering Code

 4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 18







Company Information



 4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 20



Exhibition

 4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 22



Certification

 4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size 24

FAQ

 Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea
