High Performance Submersible Level Sensors For Oil Tank
|Place of Origin:||Anhui, China|
Payment & Shipping Terms:
|Minimum Order Quantity:||1pcs|
|Price:||$35.00 - $50.00/Pieces|
|Packaging Details:||Each set into one individual carton, protection with foam. Then into master carton|
|Delivery Time:||5-8 work days|
|Payment Terms:||T/T, Western Union, MoneyGram, Paypal|
|Supply Ability:||3000 Set/Sets per Week water level sensor|
|Customized Support:||OEM, ODM||Pressure Range:||0...1~200 Metres|
|Accuracy:||0.2%FS, 0.5%FS,||Output Signal:||4-20mA, 0-5V, 1-5V, 0.5-4.5V, 0-10V|
|Application:||Rainwater, Drinking Water,Wastewater, Car Washes, Seawater||Ingress Protection:||IP68|
|Power Supply:||12~36VDC||Working Temperature:||-40~85 ℃|
|Pressure Type:||Gauge||Housing Material:||304SS, 316L|
|Sensor Contact:||316L||Port:||Shanghai, Ningbo, Shenzhen, Guangzhou|
Submersible Oil Tank Level Sensors,
316L Sensor Contact Oil Tank Level Sensors
Low Price RS485 4-20ma Submersible Oil Tank Liquid Water Hydrostatic Sensor Level Transmitter Probe
- Our WNK8010 liquid leve sensor with high performance diffused silicon piezoresistive pressure sensor as the measuring element,
- With the reliable amplified circuit and precision temperature compensation, to transfer the gauge or absolute pressure of measurement medium to standard voltage or current signal.
- This product comes with compact profile, easy to install, it can measure the level height directly when through into the liquor.
• Water tank level measurement and control.
• Fuel tank level measurement and monitor (diesel, gasoline, kerosene and so on).
• Liquid level measuring in tank, rivers, lake, sea, well, tube, underground water and so on.
• Special occasion such as high temperature liquid (up to 100 degree C), strongly corrosion liquid level measurement (request by customized.)
• Adopting diffusion silicon oil-filled sensor
• Max measure range up to 200 meters or more
• High Stability, provide 0.1, 0.2, 0.5 accuracy for option
• Factory direct price
Low Cost Water Level Sensor For Deep Well/ Open Tank/Pool
Q: Are you trading company or manufacturer ?
A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.
Q: What's your quality control system?
A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.
Q: What is the warranty of your products?
A: 12 month from shipment date, for non-man-made damages.
Q: Shipping and Delivery
A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.
Large orders are recommended to ship by sea
