36VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor

36VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor

36VDC Water Level Transmitter

WNK hydrostatic liquid level sensor

WNK Water Level Transmitter

Place of Origin:

Anhui, China

Brand Name:

WNK

Model Number:

wnk8010

Contact Us
Request A Quote
Product Details
Grade:
Industrial
Warranty:
1 YEAR
Customized Support:
OEM, ODM
Pressure Range:
0...1~200 Metres
Accuracy:
0.2%FS, 0.5%FS,
Output Signal:
4-20mA, 0-5V, 1-5V, 0.5-4.5V, 0-10V
Application:
Rainwater, Drinking Water,Wastewater, Car Washes, Seawater
Ingress Protection:
IP68
Power Supply:
12~36VDC
Working Temperature:
-40~85 ℃
Pressure Type:
Gauge
Housing Material:
304SS, 316L
Sensor Contact:
316L
Port:
Shanghai, Ningbo, Shenzhen, Guangzhou
Highlight:

36VDC Water Level Transmitter

,

WNK hydrostatic liquid level sensor

,

WNK Water Level Transmitter

Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
$35.00 - $50.00/Pieces
Packaging Details
Each set into one individual carton, protection with foam. Then into master carton
Delivery Time
5-8 work days
Payment Terms
T/T, Western Union, MoneyGram, Paypal
Supply Ability
3000 Set/Sets per Week water level sensor
Product Description

4-20mA Submersible Liquid Level Transmitter/Hydrostatic Water Level Sensor





-  Our WNK8010 liquid leve sensor with high performance diffused silicon piezoresistive pressure sensor as the measuring element,

-   With the reliable amplified circuit and precision temperature compensation, to transfer the gauge or absolute pressure of measurement medium to standard voltage or current signal.

 This product comes with compact profile, easy to install, it can measure the level height directly when through into the liquor.



Applications

•   Water tank level measurement and control.

•   Fuel tank level measurement and monitor (diesel, gasoline, kerosene and so on).

•   Liquid level measuring in tank, rivers, lake, sea, well, tube, underground water and so on.

•  Special occasion such as high temperature liquid (up to 100 degree C), strongly corrosion liquid level measurement (request by customized.)



 Features

•   Adopting diffusion silicon oil-filled sensor

•   Max measure range up to 200 meters or more

•   High Stability, provide 0.1, 0.2, 0.5 accuracy for option

•   Factory direct price

Product Name
 High Stability 4-20mA Liquid Level Sensor Transmitter For Drinking Water
Pressure measurment
Liquid,Water
Accuracy
±0.25% FS/year, ±0.5% FS/year
Output
4-20mA, 1-5V, 0.5-4.5, 0-5V, 0-10V, IIC,HART,RS485
Power supply
24V/12V/5V/3.3V
Ambient/Process/Compensation temperature
-20~80℃
Housing material
Stainless steel
Ingress Protection
IP68
















Product Show



36VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 1

36VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 336VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 536VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 736VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 9







 36VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 11

Specifications

 36VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 13


   Low Cost Water Level Sensor For Deep Well/ Open Tank/Pool

Ordering Code

 36VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 15







Company Information



 36VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 17



Exhibition

 36VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 19



Certification

 36VDC Water Level Transmitter , WNK Hydrostatic Liquid Level Sensor 21

FAQ

 Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea
