The Housing is made of aluminum with specific explosion-proof function
 |
Industrial 4-20mA RS485 HART Integrated Ultrasonic Level Transmitter
Product Details:
| Place of Origin: | Anhui, China |
| Brand Name: | WNK |
| Model Number: | WNKPWCS72 |
Payment & Shipping Terms:
| Price: | $120.00 - $300.00/Units |
|---|---|
| Supply Ability: | 2000 Unit/Units per Month Ultrasonic Level transmitter |
|
Detail Information |
|||
| Grade: | Industrial | Warranty: | 1year |
|---|---|---|---|
| Customized Support: | OEM, ODM | Product Name: | Ultrasonic Level Transmitter |
| Measuring Range: | 0.3-10m | Process Connection: | G1 1/2A Or Flange, Bracket |
| Housing Material: | Aluminum/ABS | Accuracy: | 0.25%FS |
| Transducer Material: | PA66+GF30/PVDF | Process Temperature: | -40-70℃ |
| Process Pressure: | -0.02-0.1MPa | Output: | 4-20 MA/HART/RS485/Modbus |
| Explosion-proof Grade: | Exia IIB T6 Ga | Port: | Shanghai |
Product Description
Industrial 4-20mA RS485 HART Integrated Ultrasonic Level Transmitter
Aluminum Housing material
Different transducers can be selected for different measuring media, standard transducer can be selected for common environment and anticorrosive sealed transducer can be selected for special environment
Echo curve display function
False echo storage function
Frequency adjustment function
Noise filteringfunction
Mesuring range can reach 20m while measuring the liquid with 0.25% high accuracy
Application Case
Product Paramenters
Model | Measuring Range | Process Connection | Transducer Material |
PWCS71 | 0.25-5m | G11/2"A/Flange/Bracket | PA66+GF30/PVDF |
PWCS72 | 0.3-10m | G2"A/Flange/Bracket | PA66+GF30/PVDF |
PWCS73 | 0.4-10m | M66*2/Flange/Bracket | PA66+GF30/PVDF |
PWCS74 | 0.5-20m | M95*2/Flange/Bracket | PA66+GF30 |
Installation Guide
The transducer shall be vertical to the medium surface
The equipment shall not be installed in the middle of the tank top
The installation position shall avoid obstacles as much as possible
The installation position shall avoid obstacles as much as possible
Company Profile
FAQ
Q: Are you trading company or manufacturer ?
A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient
pressure/level/temperature measuring instruments.
Q: WHAT'S YOUR QUALITY CONTROL SYSTEM?
A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.
Q: WHAT IS THE WARRANTY OF YOUR PRODUCTS?
A: 12 month from shipment date, for non-man-made damages.
Q: SHIPPING AND DELIVERY
A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.
Large orders are recommended to ship by sea
A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient
pressure/level/temperature measuring instruments.
Q: WHAT'S YOUR QUALITY CONTROL SYSTEM?
A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.
Q: WHAT IS THE WARRANTY OF YOUR PRODUCTS?
A: 12 month from shipment date, for non-man-made damages.
Q: SHIPPING AND DELIVERY
A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.
Large orders are recommended to ship by sea
