Liquid Electronic Pressure Sensor , 0.2% Smart Pressure Transducer I2C SPI
|Place of Origin:||Anhui, China|
Payment & Shipping Terms:
|Price:||$10.00 - $20.00/Pieces|
|Packaging Details:||each pc product in one individual plastic bag with protection.|
|Supply Ability:||2000 Set/Sets per Week pressure sensor|
|Warranty:||1 YEAR||Customized Support:||OEM, ODM|
|Measured Media:||Liquid, Gas And Steam||Interface Type:||I2C, SPI|
|Accuracy:||±0.2%||Total Error Band:||±1.0%|
|Pressure Range:||0-10Kpa~7Mpa||Housing Material:||316L|
|Power Supply:||3.3V, 5V||Product Name:||Smart Digital Pressure Transducer I2C/SPI Liquid Pressure Sensor|
Liquid Electronic Pressure Sensor,
0.2% Smart Pressure Transducer,
SPI Smart Pressure Transducer
Smart Digital Pressure Transducer I2C/SPI Liquid Pressure Sensor
WD19 Digital I2C/SPI Output Pressure Sensor
D19 series are based on piezoresistive silicon pressure sensors packaged in a 316L stainless steel housing. The sensing package utilizes silicon oil to transfer pressure from the 316L diaphragm to the sensing element. This digital output pressure sensor supports I2C and SPI interface protocols, may come in a 3.3 or 5.0Vdc supply voltage.
It is designed for o-ring mounting for the applications where compatibility with corrosive media is required.A custom ASIC is used for temperature compensation, offset correction, and provides a digital output of 0~100%.
High stability and high accuracy
Low cost OEM
Suited for pressure range: 0-40Kpa…7Mpa
Wide temperature compensation range: total error<1%
Measurable of corrosive media ( media compatible with 316L)
Standard mounting size
Communication: I²C or SPI
Q: Are you trading company or manufacturer ?
A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.
Q: What's your quality control system?
A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.
Q: What is the warranty of your products?
A: 12 month from shipment date, for non-man-made damages.
Q: Shipping and Delivery
A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.
Large orders are recommended to ship by sea
