10bar 20bar Gas Pressure Transducer 100 times overload

10bar 20bar Gas Pressure Transducer 100 times overload

Product Details:

Place of Origin: Anhui, China
Brand Name: WNK
Model Number: W21

Payment & Shipping Terms:

Price: $5.00 - $10.00/Pieces
Packaging Details: each pc product in one individual bag with protection.standard packing.
Supply Ability: 2000 Piece/Pieces per Week Gas Pressure Sensor
Get Best Price Contact Now

Detail Information

Warranty: 1 Year Customized Support: OEM, ODM
Output: 4-20mA/0-5V/0-10V/0.5-4.5vdc Range: 0-400Kpa~10MPa
Accuracy: ±0.5%, ±1%, Power Supply: 3.3V, 5V, 12V, 24V
Pressure Type: GP, AP, Sealing Pressure Material: Al2O3
Toal Error Band: ±1.0% Housing Materials: 316L
Burst Pressure: P*10 Interface Type: I2C, SPI
Port: Shanghai
High Light:

20bar Gas Pressure Transducer

,

100 Times Gas Pressure Transducer

Product Description

Low Cost 10bar 20bar Pressure Sensor For Water Gas

      W21 series is dry ceramic capacitive pressure sensor made by special technology processed ceramic.its operating temperature range up to -40  to 135  with high accuracy and high stability in measurement.

With high output and wide range, W21 ceramic capacitive sensor is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement.

10bar 20bar Gas Pressure Transducer 100 times overload 0



  >> Main Features








1.  Robust ceramic capacitive sensitive diaphragm;
2.  Excellent performance in corrosion and abrasion application;

3.  Normal pressure sensor diameter suitable for compact pressure transducer;
4.  Suitable for pollution and corrosive environment;
5.  Superb positive and negative gauge pressure function;
6.  Highest overload up to 100 times of pressure range;
7.  Rapid response, no hysteresis;
8.  Wide operating temperature range -40~135℃;

9.  0.5 ... 4.5V,  I²C , SPI & 4~20mA output optional;

Technical Parameters



10bar 20bar Gas Pressure Transducer 100 times overload 2

 10bar 20bar Gas Pressure Transducer 100 times overload 4

Application:



1.  Pressure measurement of gas, vapor or liquid in various areas;
2.  Liquid level, volume or mass measurement;
3.  Integrated in a variety of user-defined solutions.

  10bar 20bar Gas Pressure Transducer 100 times overload 6

  >> Appearance and dimensions







10bar 20bar Gas Pressure Transducer 100 times overload 8





  >> Working principle







10bar 20bar Gas Pressure Transducer 100 times overload 10

      When pressure resumes normal, its performance is not affected. W21 dry ceramic capacitive pressure sensor completely solved poor overload in low range shortcomings of diffused silicon sensor, and has been new generation products if diffused silicon sensor. The sensor has excellent temperature and time stability, and can contact with most media directly.

     As no liquid transmission and no liquid filling in ceramic capacitive sensor, there will be no production process pollution. So it can be widely applied in food, medicine, refrigeration, automotive and etc. In addition to dry ceramic capacitive diaphragm, installation direction will not have any influence. Pressure transmitter with it as sensitive component can be widely used various pressure measurement situations.

Hot Product



10bar 20bar Gas Pressure Transducer 100 times overload 12





Company Information

10bar 20bar Gas Pressure Transducer 100 times overload 1410bar 20bar Gas Pressure Transducer 100 times overload 1610bar 20bar Gas Pressure Transducer 100 times overload 1810bar 20bar Gas Pressure Transducer 100 times overload 2010bar 20bar Gas Pressure Transducer 100 times overload 2210bar 20bar Gas Pressure Transducer 100 times overload 24




FAQ

 Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea
